MoGo Pro+

1. Please ensure the remote control is within 10 cm of the device.
2. Press the “Return” and “Home” buttons on the remote control simultaneously until the indicator light begins flashing. This means that the remote control has entered pairing mode.
3. When a "Ding" sound is heard, the connection is successful. Note: If the pairing fails, it will exit after 30 seconds. Please repeat the above steps after it exits.

No.
"XGIMI Assistant" works for none-android-based models, such as the XGIMI H2.

 The XGIMI MoGo Pro+ is installed with the official Google Android TV system. Therefore, the "Android TV" app is a better option:
Please download the "Android TV" app on your phone and pair it with MoGo Pro+, using the same WiFi connection. You can then use your phone as a remote.

 Please refer to the video tutorial below:

Yes.
The XGIMI MoGo Pro+ is installed with the official Google Android TV system. Therefore, the "Android TV" app is a better option: Please download the "Android TV" app on your phone and pair it with MoGo Pro+, using the same WiFi connection. You can then use your phone as a remote. For Android users, the XGIMI team is currently working on updating this feature; please stay tuned.
Please refer to the video tutorial below:

The XGIMI remote control makes everything simple:
1. Power button: powers the projector on/off.
2. Settings shortcut: access/adjust settings for 3D video setup, image quality, sound output, Keystone Correction, and more.
3. Voice control: allows you to use simple voice commands via Google Assistant to open apps, search for your favorite content, or play music.
4. Directional buttons: Provides simple navigation through the XGIMI UI.
5. Volume button: adjusts the volume up/down; also adjusts the manual focus feature.
6. Menu button: allows you to customize video settings.
7. Focus button: enables the autofocus feature; press and hold to enter the manual focus page.
8. Home button: returns to the home page from any screen.
9. Return button: quickly directs you back to a previous screen.

1: While playing a 3D compatible movie or video, click the “Shortcut” button on your XGIMI remote controller.
2: Select “3D Video Setup”
3: Choose the corresponding 3D mode.
4: When the images combine, and the display blurs, the 3D feature is enabled.
5: Adjust the buttons on your XGIMI 3D glasses until the image clears. Please also ensure that your XGIMI 3D glasses are fully charged.

Tip: For a better viewing experience, it is recommended that you use XGIMI 3D glasses.

Charging time: around 2-3 hours

Power on: Press the power button; A green LED light flash means the glasses have been turned on.

Power off: Long press the power button for 3 seconds; the green LED light will flash 3 times, and the glasses will power off.

Standby status: After 5 seconds without a 3D signal, the glasses will automatically switch to standby mode; the green LED light will also flash every 5 seconds.

USB charging: A red indicator light will appear when the glasses are charging and will automatically shut off once the glasses are fully charged.

Low battery mode: When the 3D glasses are low on battery, the green LED light will flash 5 times, then 2 times every 10 seconds, indicating the need for charging.

To enable the XGIMI 3D glasses:
1. Press once to power them on.
2. Press a second time to adjust the image quality, and continue pressing until the image is clear.
3. When playing videos on your projector, you need to choose the “up/down 3D” or “left/right 3D” effect to ensure an optimized viewing experience.

The XGIMI MoGo Pro+ features Chromecast built-in, allowing you to cast your favorite entertainment apps, movies, music, games, and videos from your Android or iOS devices. (Chromecast-supported apps).
Open media apps on your external device and search for the XGIMI MoGo Pro+ to connect via Chromecast built-in.

The XGIMI MoGo Pro+ is installed with the Official Google Android TV system, granting you full access to the Google service eco-system. Please download "Google Home" on your Android device and connect it to the XGIMI MoGo Pro+ using the same WiFi signal. Tap the screen-mirroring button on the Google Home app homepage.
Please refer to the video tutorial below:

For IOS device users, you can screen mirror via below steps:
1. Please install "MagiCast"app from Google Play Store or Desktop Manager app, it's a XGIMI self-developed tool
2. Start "MagiCast" on XGIMI MoGo Pro plus
3. Open "Cast Screen" in any Iphone/Ipad/Macbook and make sure its under the same WiFi signal with the projector

For the wireless connections between the XGIMI MoGo Pro+ & PCs
1. Please ensure your PC & XGIMI MoGo Pro+ are using the same WiFi connection.
2. Open the Chrome browser on your PC and click the "Customize & Control" button in the upper right corner
3. Click "Cast" then search for the XGIMI MoGo Pro+ to mirror the PC screen.
Please refer to the video tutorial below:

Yes. MoGo Pro+ is equipped with 16GB of internal storage. For local files or media sources, it's recommended to use an external USB/hard drive. (Up to 4T)

Yes.
The XGIMI MoGo Pro+ also offers one HDMI port for external connections, making screen mirroring much easier for daily usage. Please connect your external device via the HDMI port, and the XGIMI MoGo Pro+ will automatically switch to the HDMI page.

For wireless connections between the XGIMI MoGo Pro+ & PCs/Laptops:
1. Please ensure the PC/laptop & the XGIMI MoGo Pro+ are using the same WIFI signal.
2. Open Chrome browser on the PC/laptop.
3. Click the "Customize & Control" button in the upper right corner, then "Cast".
4. Search for the XGIMI MoGo Pro+, then connect.
Please refer to the video tutorial below:

Yes.
The XGIMI MoGo Pro+ offers one HDMI port for external connections. Customers are free to connect any TV stick for more streaming apps.

Tip: MoGo Pro+ USB port also offers enough power to support TV sticks.

Yes.
The XGIMI MoGo Pro+ supports Bluetooth 4.2/5.0 BLE, allowing you to search and connect with any Bluetooth device.
To begin pairing:
1. Go to system setup
2. Remote & Accessories
3. Add accessory

Yes.
The XGIMI MoGo Pro+ offers one HDMI port for external connections, making audio transferring much easier for daily use. Please connect the external device to the HDMI port, then follow the steps below to complete the setup:
1. Press the "Shortcut" button on the XGIMI remote control.
2. Enter ""Sound Settings" -- "Sound Output" -- "Sound" -- "Output" -- "Internal speaker/SPDIF/ARC".

The XGIMI MoGo Pro+ is installed with the official Google Android TV system, which offers 5000+ apps for daily entertainment. Customers are free to download any available apps from the Google Play Store.
If you can't find the desired app from the Play Store, it's recommended to install the application via a USB disk:
1. Please download the TV version of the APK file with your PC/laptop.
2. Copy the APK file to the root directory of the USB disk.
3. Connect the USB to the XGIMI MoGo Pro+, and locate the APK file to install it directly.

Please contact the XGIMI service team at service-usa@xgimi.com for further details.

No.
Please don't install any firmware that is not supported by the XGIMI MoGo Pro+. Refer to the official XGIMI website for information on the latest firmware updates.
For further instructions, please contact the XGIMI service team.

Yes.
1. Please download "Desktopmanager" from the Google Play Store.
2. Please install WPS from "Desktopmanager" to use the XGIMI MoGo Pro+ as an office tool.

Yes.
To enable the CEC feature: Go to "System Setup" -- "Projector Settings" -- "CEC Settings" -- "CEC on/off"

Yes.
The XGIMI MoGo Pro+ supports automatic vertical keystone correction and manual horizontal keystone correction ( ±40 Degrees), allowing users to set up their device where they desire with incredible ease.
For further adjustment, please use the 4-point manual keystone correction feature.

Yes.
The screen zoom feature allows you to alter the XGIMI MoGo Pro+'s screen based on your specific needs. To enable screen zoom:
Go to "System Setup" -- "Projector Settings" -- "Keystone Correction" -- "Screen Zoom"

The throw ratio describes the distance from the lens to the screen (throw) to the screen width. When the distance from the lens to the screen is the same, the smaller the projection ratio is, the larger the screen can throw.
Projection ratio: 1.2:1

MoGo Pro+ projects up to 200 inches, which meets various projection requirements.
MoGo Pro+ features 300 ANSI lumens. For the best viewing experience, we recommend using a 60-120" screen size.
Projection ratio: 16:9

Diagonal size:
38 inches @1m (1.8m*0.5m); 76 inches@2m (1.7m&0.9m); 114 inches@3m (2.5m*1.4m);
151 inches@4m (3.4m*1.9m); 189 inches@5m (4.1m*2.4m); 227 inches@6m (5m*2.8m)

The XGIMI MoGo Pro+ will send a push notification of new firmware updates on the homepage. Select "Details" to begin updating the firmware. If the notification is dismissed, please follow the steps below to check for new updates:
1. Please ensure your WiFi connection is stable.
2. Go to "Settings" -- "Device Preferences" -- "About" -- "System Update" -- "Check for update"

Tip: Please avoid stopping the update process or disconnecting the WiFi until it is complete.

Go to "System Setup" -- "Device Preferences" -- "About"
There, you'll find the Device name, Model, Status (serial number), Kernel version, and Build (firmware version).

1. While on the XGIMI MoGo Pro+ home page, press the "Shortcut" button on the XGIMI remote control.
2. There, you can switch HDMI versions between "HDMI1.4/2.0".

1. Plug in the power supply and press MoGo Pro+'s power button to begin the initial setup.
2. After finishing the initial setup, the Bluetooth remote has successfully paired.
3. You can now use the XGIMI remote control to power MoGo Pro+ on/off within 5 seconds.

Tip: Unplug the power supply and long-press MoGo Pro+'s power button for 3-7 seconds to turn off the projector completely.

Yes. The XGIMI MoGo Pro+ supports HDR10 decoding.

To enable automatic focus:
1. Go to "System Setup" -- "Projector Settings" -- "Focus Settings" -- "Auto Focus" -- "Startup/Auto Focus upon Motion"
2. Press the "Focus" button on the XGIMI remote control to focus the image automatically.

The XGIMI MoGo Pro+ supports both automatic and manual focus.
For manual focus, switch off the "Focus" key on the bottom of the XGIMI remote control, then use the "Volume" buttons to adjust the image until it is clear.

To use the XGIMI MoGo Pro+ as a Bluetooth speaker:
1. Turn on theXGIMI MoGo Pro+;
2. Pair your external device (e.g., smartphone) with the XGIMI MoGo Pro+ via Bluetooth connection;
3. Long-press the "Power" button on the XGIMI remote for 2-4 seconds;
4. Choose "Display off".

Charging Time: The XGIMI MoGo Pro+ fully charges in 3.5-5 hours. Charge it until the green indicator light goes off.
(PS: When the green indicator light goes off, it means the battery is ≥ 90%)

Battery Life: Users can watch 2 to 4-hour videos/movies on a single charge (subject to actual usage)

Note: The actual battery life is subject to using environments, external conditions, and using habits.

To complete the initial setup, please log into your Google account.
 After entering the Google Android TV UI homepage, please follow the steps below to add/delete a Google account:
 1. Go to "System Setup" -- "Account" -- "Sign in" -- "Add account/Delete account"
